HP 560
Surface Printable, Heavy Duty Grade Hot Melt Packaging Tape
Heavy duty grade hot melt packaging tape for manual or automated industrial sealing of heavy, bulky cartons, including overstuffed or under-filled cartons, in high stress and extreme handling conditions. Designed to be tough with an aggressive adhesive and exclusive release-coat technology for consistent unwind, HP 560 is directly printable with all leading brands of solvent inks and delivers faster drying times for more efficient use of machines and superior ink anchorage without pickoff.
HP 560
Surface Printable, Heavy Duty Grade Hot Melt Packaging Tape
Heavy duty grade hot melt packaging tape for manual or automated industrial sealing of heavy, bulky cartons, including overstuffed or under-filled cartons, in high stress and extreme handling conditions. Designed to be tough with an aggressive adhesive and exclusive release-coat technology for consistent unwind, HP 560 is directly printable with all leading brands of solvent inks and delivers faster drying times for more efficient use of machines and superior ink anchorage without pickoff.
- Heavy duty grade packaging tape
- Surface printable with leading brands of solvent inks
- Instant, permanent bond to a wide range of substrates and surfaces
- Special release coating for consistent, low force unwind off the roll
- Performs reliably to the core for efficient tape consumption
Technical data for HP 560
Sizes & Colors
Colors Available
| Standard Widths | 11.33 in, 11.96 in, 5.66 in 144 mm, 150 mm, 288 mm |
|---|---|
| Standard Lengths | 1000 yd 914 m |
Construction
| Adhesive | Synthetic rubber/resin hot melt adhesive |
|---|---|
| Backing | Directly printable, 50 micron biaxially oriented polypropylene cast film |
Applicable Standards
| ASTM D 1974/D 1974M-22 |
| CID A-A-1684C |
| FDA Indirect Contact CFR 21, 175.105 |
Properties
| Adhesion to Backing | 6 oz/in width 0.66 N/10 mm |
|---|---|
| Application Temperature Max | 110 F 43 C |
| Adhesion to Stainless Steel | 58 oz/in width 6.35 N/10 mm |
| Application Temperature Min | 35 F 2 C |
| Elongation | 150% 150% |
| Standard Core Size | 3 in |
| Holding Power to Fiberboard | 45,000 minutes 45,000 minutes |
| Service Temperature Max | 150 F 66 C |
| Service Temperature Min | -20 F -29 C |
| Tensile Strength - Longitudinal Direction | 42 lbs/in width 73.6 N/10 mm |
| Tensile Strength - Transverse Direction | 74 lbs/in width 129.6 N/10 mm |
| Thickness | 3.0 mils 0.076 mm |
Storage & Usage Conditions
Tape should be stored in its original packaging in a cool, dry area away from direct sunlight and should be used within 12 months of date of shipment. Surfaces to which tape is applied should be clean, dry and free of grease, oil or other contaminants.
Physical and performance characteristics shown above are obtained from tests recommended by PSTC, ASTM, government agencies or Shurtape Technologies, LLC, Quality Assurance and Technical Service departments and do not represent a guarantee of product performance. Individual rolls may vary slightly from these averages. The user should determine whether the product is fit for a particular purpose and is suitable for the user’s method of application before use.
