FSL 055
FrogTape™ Pro Grade Flashing Tape
An all-weather, high-performance flashing tape for creating weatherproof seals around windows, doors and other building openings in residential and commercial construction applications. FrogTape™ Pro Grade Flashing Tape combines ShurGRIP™ high-performance solventless acrylic adhesive with a conformable film backing that easily bends around edges, corners and other building transitions and bonds to a wide variety of building materials. Engineered using exclusive UV curing technology, this flashing tape does not contain volatile organic compounds (VOC) and won’t react with caulks and sealants, ensuring durable bonds after installation.
- All-weather performance with 12-month UV resistance
- Wide installation temperature range from 0 F (-18 C) to 150 F (65 C) with long-term performance after install in temperatures ranging from -40 F (-40 C) to 240 F (115 C)
- Initially repositionable adhesion to building materials and substrates such as OSB, glass faced gypsum and concrete and compatible with sealants and caulking as well as flexible and rigid PVC window flanges; seals around nails, screws and other fasteners
- Self-healing around nails and protrusions for a waterproof seal
- Saves time – no primers needed* (*in most applications)
- Wider widths (6 in, 9 in, 12 in) feature a split release liner for easy removal
- Meets AAMA 711-22
Technical data for FSL 055
Sizes & Colors
Colors Available
| Standard Widths | 12 in, 3.75 in, 6 in, 9 in 152 mm, 228.6 mm, 304.8, 96.6 mm |
|---|---|
| Standard Lengths | 30 ft, 50 ft, 75 ft 15.3 m, 22.9 m, 9.1 m |
Construction
| Liner | Moisture stable 2-mil polyester release liner |
|---|---|
| Adhesive | 5.0 mils solventless acrylic adhesive |
| Backing | 5.0 mils black polyolefin film |
Applicable Standards
| AAMA 711-22 |
Properties
| Standard Core Size | 3 in |
|---|---|
| Adhesion to Exterior Glass Faced Gypsum | >1.5 lbs/in width >0.26 N/mm |
| Adhesion to OSB | >1.5 lbs/in width >0.26 N/mm |
| Adhesion to Plywood | >1.5 lbs/in width >0.26 N/mm |
| Adhesion to Rigid PVC | >1.5 lbs/in width >0.26 N/mm |
| Application Temperature Max | 150 F 65 C |
| Application Temperature Min | 0 F -18 C |
| MD Tensile Strength | 16.3 lbs/in width 28.5 N/10mm |
| Adhesion to Anodized Aluminum | >1.5 lbs/in width >0.26 N/mm |
| Service Temperature Max | 240 F 115 C |
| Service Temperature Min | -40 F -40 C |
| Thickness - Without Liner | 10.0 mils 0.25 mm |
Storage & Usage Conditions
Tape should be stored in its original packaging in a cool, dry area away from direct sunlight and should be used within 18 months of date of shipment. Surfaces to which tape is applied should be clean, dry and free of grease, oil and/or other contaminants.
Physical and performance characteristics shown above are obtained from tests recommended by PSTC, ASTM, government agencies, or Shurtape Quality Assurance and Technical Service departments and do not represent a guarantee of product performance. Individual rolls may vary from these averages. The user should determine whether the product is fit for a particular purpose and is suitable for the user’s method of application before use.
