CP 325
FrogTape® Performance Grade High Temperature, Medium-High Adhesion Masking Tape
Performance grade, medium-high adhesion masking tape for use in moderate temperatures in the transportation and metal fabrication industries. For use in temperatures up to 325 F (for up to 30 minutes), FrogTape® 325 Pink is a user-friendly, durable solution that delivers sharp paint lines, clean removal and consistent unwind in a range of industrial applications and environments.
CP 325
FrogTape® Performance Grade High Temperature, Medium-High Adhesion Masking Tape
Performance grade, medium-high adhesion masking tape for use in moderate temperatures in the transportation and metal fabrication industries. For use in temperatures up to 325 F (for up to 30 minutes), FrogTape® 325 Pink is a user-friendly, durable solution that delivers sharp paint lines, clean removal and consistent unwind in a range of industrial applications and environments.
- Excellent adhesion to metal, rubber, plastic, anodized aluminum, chrome and fiberglass
- Resistant to water, salt water, various solvents and abrasives
- Compatible with gel coats, multi-part epoxy topcoats, and antifouling bottom paints for marine applications, as well as solvent based and waterborne, aqueous paints and coatings for automotive
- Resistant to water, various solvents and gel coats
- Residue-free removal
- Temperature-resistant up to 325 F (for up to 30 minutes)
- Remove tape at room temperature (70 F +/- 10 F) after baking
Technical data for CP 325
Sizes & Colors
Colors Available
| Standard Widths | 0.47 in, 0.70 in, 0.94 in, 1.41 in, 1.88 in, 2.83 in 12 mm, 18 mm, 24 mm, 36 mm, 48 mm, 72 mm |
|---|---|
| Standard Lengths | 60 yds 55 m |
Construction
| Adhesive | Rubber-based adhesive |
|---|---|
| Backing | Fine structured crepe |
Applicable Standards
| ASTM D 6123/D 6123M-97 (2012), Type I |
| AMS-T-21595 |
Properties
| Standard Core Size | 3 in |
|---|---|
| Adhesion to Stainless Steel | 34 oz/in width 3.72 N/10 mm |
| Elongation | 12% 12% |
| Service Temperature Max | 325 F (up to 30 minutes) 163 C (up to 30 minutes) |
| Service Temperature Min | 40 F 4 C |
| Tensile | 25 lbs/in width 43.8 N/10 mm |
| Thickness | 6.4 mils 0.16 mm |
Storage & Usage Conditions
Tape should be stored in its original packaging in a cool, dry area away from direct sunlight and should be used within 12 months of date of shipment. Surfaces to which tape is applied should be clean, dry and free of grease, oil or other contaminants.
Physical and performance characteristics shown above are obtained from tests recommended by PSTC, ASTM, government agencies or Shurtape Technologies, LLC, Quality Assurance and Technical Service departments and do not represent a guarantee of product performance. Individual rolls may vary slightly from these averages. The user should determine whether the product is fit for a particular purpose and is suitable for the user’s method of application before use.
